Washington Street Map / Laser-cut design
Washington. Four map layers.
SVG, DXF and CDR files for a four-layer Washington street map. Choose a round, square or hexagonal frame around the road and water pattern.
Digital design · SVG + DXF + CDR
No physical model or materials are shipped.
01 /The design
Compare the three map outlines.
The preview places the round, square and hexagonal versions together. The road pattern and water shapes remain the focus inside each outline, with Washington lettering at the edge.
The package includes SVG, DXF and CDR design files for the four-layer artwork. Check the current file dimensions and the smallest road details before choosing a cutting size.
Four map layers
Prepare the matching layers together at a common scale.
Three frame shapes
Choose the round, square or hexagonal design.
Road and water detail
Contrasting finishes help the map pattern stand apart from the backing.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Review the current layout size and minimum-size guidance in the supplied files. Test the finest roads and narrow connections, scale every layer equally and inspect the stack before fixing it together.
Before you start.
- Design
- Four-layer Washington street map
- Vector formats
- SVG, DXF, CDR
- Frame options
- Round, square or hexagonal
Which frame shapes are included?
The design includes round, square and hexagonal frame options. Keep the four layers for your chosen outline at the same scale and check their alignment before cutting.
What do I receive?
SVG, DXF and CDR design files for the four-layer street map with round, square and hexagonal frame options. An assembly guide is not confirmed. No physical map or material is supplied.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
Contact 21CNCStudio to discuss permission before commercial use. Do not redistribute the digital files without the author’s permission.
03 /From the studio to your workbench
Choose your Washington map shape.
View the Washington Street Map file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
