Oregon Layered Map / Laser-cut design
Oregon. Eight layers.
SVG, DXF, AI and CDR files for eight-layer Oregon artwork. Pale mountains, an orange skyline and sailboats over blue water sit inside the state outline.
Digital design · SVG + DXF + AI + CDR
No physical model or materials are shipped.
01 /The design
Sailboats below the skyline.
White sailboats sit across the blue foreground beneath a band of orange buildings. Pale mountain shapes fill the background, with Oregon lettering at the lower-left edge.
The recommended size is 260 × 194 mm. Prepare all eight layers together and choose contrasting finishes to keep the boats, buildings and background distinct.
Eight-layer landscape
Arrange the matching shapes from background to foreground.
Oregon outline
The state silhouette frames the mountain and waterfront scene.
Four vector formats
SVG, DXF, AI and CDR files are supplied.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Check the fine sailboat, skyline and mountain connections at your intended size. Scale every layer equally, cut a detailed sample and dry-stack the complete design before fixing it together.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design
- Eight-layer Oregon artwork
- Vector formats
- SVG, DXF, AI, CDR
- Recommended size
- 260 × 194 mm
Does this show roads or elevation data?
This is a decorative state-outline scene with mountains, buildings and sailboats. It is not presented as a street network or a topographic map.
What do I receive?
SVG, DXF, AI and CDR design files for the eight-layer Oregon artwork. An assembly guide is not confirmed. No physical artwork or material is supplied.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
The files are for personal use. Contact 21CNCStudio before commercial use or selling finished items. Do not resell, share or redistribute the digital files without permission.
03 /From the studio to your workbench
Build your Oregon landscape.
View the Oregon Layered Map file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
