New Jersey Layered Map / Laser-cut design
New Jersey. A coastal scene.
SVG, DXF, AI, CDR and EPS files for layered New Jersey artwork in 3 mm plywood. Cut the lighthouse, green scenery and blue water inside the long state outline.
Digital design · SVG + DXF + AI + CDR + EPS
No physical model or materials are shipped.
01 /The design
A lighthouse in the coastal scene.
The white lighthouse stands through the centre of the composition, with green landscape and blue water below. Pale sky and cloud shapes fill the top, while New Jersey lettering follows the lower edge.
The recommended minimum size is 260 × 140 mm. Five vector formats are supplied; a layer count and assembly guide are not confirmed.
New Jersey outline
The state silhouette frames the coastal composition.
Lighthouse and water
Contrasting finishes separate the tower from the scenery around it.
Material guidance
The author specifies 3 mm plywood and a recommended minimum size.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Respect the minimum-size guidance and inspect the lighthouse and narrow state shape. Scale all layers equally, cut a detailed test section and check their order and alignment before fixing the artwork.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design
- Layered New Jersey state artwork
- Vector formats
- SVG, DXF, AI, CDR, EPS
- Recommended minimum size
- 260 × 140 mm
- Material
- 3 mm plywood
What size and material are recommended?
The design specifies 3 mm plywood and a recommended minimum size of 260 × 140 mm. Measure the material and test the finest details at your intended cutting size.
What do I receive?
SVG, DXF, AI, CDR and EPS design files for the layered New Jersey artwork. An assembly guide is not confirmed. No physical artwork or plywood is supplied.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
The files are for personal use. Contact 21CNCStudio before commercial use or selling finished items. Do not resell, share or redistribute the digital files without permission.
03 /From the studio to your workbench
Make your New Jersey scene.
View the New Jersey Layered Map file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
