Expedition Truck / Laser-cut design
Expedition Truck.
A wooden expedition truck with a tall rear cabin, an engine under the hood and a detailed cab interior. SVG and DXF files include a PDF assembly guide.
Digital design · SVG + DXF · PDF guide
No physical model or materials are shipped.
01 /The design
Look beyond the bodywork.
The tall rear cabin and roof rack give this truck its expedition profile. The front cab and six-wheel layout make it a substantial vehicle model even at display scale.
The documented design includes an engine under the hood and detail inside the cab. Use the PDF assembly sequence to work through those areas as the body takes shape.
Engine detail.
The design includes an engine beneath the hood.
Cab interior.
Interior detail adds another part of the vehicle to build.
Two material versions.
Files are described for 3 mm and 1/8 inch plywood or MDF.
A real build
Made from the files.
A physical build, with the maker’s choice of materials and finish.
02 /At your workbench
Choose your material.Make it fit.
Measure first.
Check your actual material thickness and the matching file version. Test the slots and kerf on a small cut.
Check the layout.
Open the supplied design in compatible laser software. Check that the layout fits your machine’s usable work area.
Follow the guide.
Use the PDF assembly guide to identify the parts and work through the construction sequence.
Plan this build.
Measure your material and choose the matching version. Sort the cab, engine and body parts before assembly, and test a slot before cutting the full project.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design files
- SVG + DXF
- Assembly guide
- PDF included
- Material versions
- 3 mm / 1/8 inch plywood or MDF
- Listed finished size
- 343 × 128 × 158 mm (L × W × H)
- Design details
- Engine under the hood; detailed cab interior
How much display space does it need?
The listed assembled dimensions are 343 mm long, 128 mm wide and 158 mm high. These are model dimensions, not the size of one cut part.
What do I receive?
SVG and DXF digital cutting files and PDF assembly instructions, with versions for 3 mm and 1/8 inch plywood or MDF. No physical truck, sheet material or hardware is shipped.
Can I change the scale?
Scale every part equally. Slots and tabs change with the design, so the material thickness must change in the same proportion; the finished dimensions also change. Test the fit and kerf before cutting all the parts.
Can I use the design commercially?
The files are for personal use. Contact 21CNCStudio before commercial use or selling finished items. Do not resell, share or redistribute the digital files without permission.
03 /From the studio to your workbench
Build your next expedition.
View the Expedition Truck file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
