Soldier and American Flag / Laser engraving design
Soldier and flag. An engraving image.
Normal and Jarvis PNG images for a soldier-and-flag engraving, with an SVG cutting outline and PDF usage instructions. The apparent 3D depth is a visual effect; test your material to judge the result.
Digital engraving files · PNG image + SVG outline · PDF usage instructions
No physical model or materials are shipped.
01 /The design
A standing soldier against the flag.
The soldier faces forward with an American flag filling the background. Tonal detail defines the uniform, equipment and ground around the figure. The customer photograph shows one engraving made from the design.
Extract the ZIP archive and read the PDF usage instructions. Choose the PNG version in your engraving software, then align the separate SVG outline if you want to cut around the finished image.
Two PNG versions
Normal and Jarvis images are supplied for engraving preparation.
SVG cutting outline
The outline is separate from the raster engraving image.
A material-dependent finish
Depth, detail and contrast depend on the machine, settings and material.
A real build
Made from the files.
A physical build, with the maker’s choice of materials and finish.
02 /At your workbench
Test your material.Prepare the engraving.
Extract and read.
Unpack the ZIP archive and read the PDF usage instructions. Identify the Normal and Jarvis PNG images and the separate SVG cutting outline.
Choose the image.
Open the appropriate PNG version in your engraving software. Run a small material test to judge detail and contrast before processing the whole image.
Check the outline.
If using the SVG outline to cut the shape, align it with the engraving image at the same scale and confirm the operations in your laser software.
Plan this build.
Run a small engraving test using your own material and settings. Check the image and outline at a common scale before cutting; the preview does not establish a particular engraving depth or machine setting.
Before you start.
- Project
- Engraving image with cutting outline
- Image versions
- Normal and Jarvis PNG
- Cutting outline
- SVG
- Instructions
- PDF usage instructions
- Delivery
- ZIP archive; extract before opening
Is this a 3D-printable model or a layered assembly?
This is a laser-engraving image project with a cutting outline. The 3D appearance is a visual effect; the package is not presented as an STL model or a set of stacked layers.
What do I receive?
Normal and Jarvis PNG image files, an SVG cutting outline, a ZIP project archive and PDF usage instructions. Extract the archive before opening it. No physical engraving, material or hardware is supplied.
Can I change the scale?
Keep the PNG image and SVG cutting outline aligned at the same scale. Enlarging the image does not add pixel detail; check the preview and run a small material test at your intended output size.
Can I use the design commercially?
The files are for personal use. Contact 21CNCStudio before commercial use or selling finished items. Do not resell, share or redistribute the digital files without permission.
03 /From the studio to your workbench
Prepare your soldier engraving.
View the Soldier and American Flag file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
