Saint-Pierre Cathedral Window / Laser-cut design
Saint-Pierre window. Two layers.
SVG, DXF, AI and EPS files for a two-layer circular window pattern inspired by Saint-Pierre Cathedral. Cut and align the floral tracery and backing to make a wall display.
Digital design · SVG + DXF + AI + EPS
No physical model or materials are shipped.
01 /The design
A circular pattern built from repeating curves.
The tracery spreads from a central flower towards repeated curved openings around the edge. Contrasting front and back finishes help the small shapes remain clear.
The recommended minimum size is 260 × 260 mm. SVG, DXF, AI and EPS files are included. This design does not include an assembly instruction guide.
Two-layer pattern
Cut and align the two layers to form the window design.
Floral tracery
Repeated curved openings fill the circular outline.
Four vector formats
Choose SVG, DXF, AI or EPS for preparation.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Respect the recommended minimum size and inspect the narrow tracery connections. Cut a detailed test section and check that both layers line up before fixing them together.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design
- Two-layer cathedral-inspired window
- Vector formats
- SVG, DXF, AI, EPS
- Recommended minimum size
- 260 × 260 mm
- Assembly guide
- Not included
Does the Saint-Pierre window include an assembly guide?
No. The design uses two layers and does not include an assembly instruction guide. Inspect the shapes and their alignment before cutting and fixing them together.
What do I receive?
SVG, DXF, AI and EPS files for the two-layer window artwork. No assembly instruction guide is included. No physical window, glass or material is supplied.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
Contact 21CNCStudio to discuss permission before commercial use. Do not redistribute the digital files without the author’s permission.
03 /From the studio to your workbench
Make the Saint-Pierre-inspired window.
View the Saint-Pierre Cathedral Window file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
