Cologne Cathedral Window / Laser-cut design
Gothic detail. Two layers.
A pointed arch and fine Gothic tracery, built in two layers. Digital vector files for cutting and assembling the Cologne Cathedral Window artwork.
Digital design · SVG + DXF + AI + CDR
No physical model or materials are shipped.
01 /The design
Depth behind the tracery.
The window design places a cut tracery layer over a backing layer. Contrasting finishes make the curved openings and narrow connections easier to see.
The file set lists SVG, DXF, AI and CDR vector formats, plus a PNG image. An assembly guide is not included, so inspect both layers and their alignment before cutting.
Two-layer design
A detailed front layer and backing create the relief.
Fine cutouts
Check the narrow bridges and small openings at your intended size.
Your choice of finish
Use contrasting finishes to distinguish the front detail from the backing.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Confirm the supplied design’s proportions and recommended size before cutting. Keep both layers at one scale and test a section of the fine tracery in your chosen material.
Before you start.
- Design
- Two-layer Gothic window artwork
- Vector formats
- SVG, DXF, AI, CDR
- Additional file
- PNG
- Assembly guide
- Not included
Do I need to assemble many layers?
This design uses two layers. Check their orientation and alignment before fixing them together; the file set does not include an assembly guide.
What do I receive?
SVG, DXF, AI and CDR vector files, plus PNG. No assembly guide or physical artwork is included.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
Check the current listing licence for your intended use. Do not redistribute or resell the digital files; ask the studio about permissions for making finished items for sale.
03 /From the studio to your workbench
Cut the window detail.
View the Cologne Cathedral Window file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
