R2-D2 Layered Art / Laser-cut design
R2-D2. In layers.
R2-D2’s dome, body panels and two side legs become a four-layer laser-cut artwork. Free release on MakerWorld planned for personal, non-commercial use.
Digital design · SVG + DXF · MakerWorld release planned
No physical model or materials are shipped.
01 /The design
A familiar droid in four layers.
The dome and panel shapes make R2-D2 recognisable even before the layers are stacked. Each level separates a different part of the face and body, giving the flat silhouette depth.
A light body with contrasting blue panels follows the illustrated finish. You can also let the material show through and use the layer edges to define the details.
Four-layer artwork.
The design builds depth by stacking cut panels.
Dome and body detail.
Small openings and inset shapes outline the droid’s familiar features.
A display project.
The finished layered piece is intended as decorative fan art.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Check the final file dimensions and smallest details before cutting. Keep the four layers at the same scale and arrange them in order before fixing them together.
Before you start.
- Design
- Four-layer droid artwork
- Documented formats
- SVG + DXF
- Use
- Personal, non-commercial fan art
- Release status
- Free MakerWorld release planned
Is this a moving droid model?
This page is for a four-layer decorative artwork. Motors, electronics and a moving droid mechanism are not part of this design.
What do I receive?
SVG and DXF are documented for this design. The final MakerWorld file package and any supporting instructions will be confirmed at release; no download is available from this page yet.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
Unofficial fan art for personal, non-commercial use. This design is not affiliated with or endorsed by Lucasfilm or Disney. Commercial-use rights are not offered here.
03 /From the studio to your workbench
Room for one more droid.
Free release on MakerWorld planned.
The release page for this design is not linked yet. The final file package will be confirmed when it is published.
Unofficial fan art for personal, non-commercial use. Not affiliated with or endorsed by Lucasfilm or Disney.
Digital design files.No physical model, material or hardware is shipped.
