North Carolina Layered Map / Laser-cut design
North Carolina. Eight layers.
Cut eight layers of North Carolina state-shaped artwork from 3 mm plywood. The SVG, DXF, AI, CDR and EPS designs combine buildings with a wooded landscape.
Digital design · SVG + DXF + AI + CDR + EPS
No physical model or materials are shipped.
01 /The design
A landscape across the North Carolina silhouette.
The long state outline frames buildings and green landscape shapes, with North Carolina lettering along the lower edge. Contrasting colours separate the overlapping layers.
The recommended size is 260 × 105 mm, using 3 mm plywood. The digital design is supplied in SVG, DXF, AI, CDR and EPS formats.
Eight-layer artwork
Align and stack all eight layers at a common scale.
North Carolina outline
The state silhouette and lettering define the finished display.
Five vector formats
Choose the format your preparation software supports.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Inspect the small buildings, trees and narrow parts of the outline before reducing the design. Test the detailed sections and dry-stack the layers before fixing them together.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design
- Eight-layer North Carolina artwork
- Vector formats
- SVG, DXF, AI, CDR, EPS
- Recommended size
- 260 × 105 mm
- Material
- 3 mm plywood
What material and size are recommended?
The design specifies 3 mm plywood and a recommended size of 260 × 105 mm. Measure your actual material, keep every layer at one scale and test the fine details.
What do I receive?
SVG, DXF, AI, CDR and EPS design files for the eight-layer artwork. An assembly guide is not confirmed. No physical artwork or plywood is supplied.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
The files are for personal use. Contact 21CNCStudio before commercial use or selling finished items. Do not resell, share or redistribute the digital files without permission.
03 /From the studio to your workbench
Layer your North Carolina scene.
View the North Carolina Layered Map file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
