Layered Lighthouse / Laser-cut design
A lighthouse. Four coastal layers.
SVG, DXF, AI and CDR files for a four-layer lighthouse display. Cut the red-and-white striped tower, small keeper building and wave-shaped base for coastal wall art.
Digital design · SVG + DXF + AI + CDR
No physical model or materials are shipped.
01 /The design
A striped tower above the waves.
The lighthouse rises from a broad base of curling wave shapes, with a small building against the tower. Contrasting finishes separate the stripes, lantern and foreground detail.
The recommended size is 290 × 241 mm. This is four-layer artwork rather than a freestanding architectural model; the customer photograph shows the completed layered display.
Four-layer artwork
Stack and align the lighthouse and wave shapes.
Coastal silhouette
The striped tower rises above a shaped wave base.
A physical example
The customer photograph shows the red, white and dark finished layers.
A real build
Made from the files.
A physical build, with the maker’s choice of materials and finish.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Inspect the wave connections and small lantern details at your intended size. Keep all four layers at one scale, test a detailed section and check alignment before fixing the artwork together.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design
- Four-layer lighthouse artwork
- Vector formats
- SVG, DXF, AI, CDR
- Recommended size
- 290 × 241 mm
- Assembly guide
- Not included
Does this include a working light or an assembly guide?
This is a layered lighthouse artwork. A lighting kit is not offered, and no assembly instruction guide is included. Inspect the layer shapes before cutting and stacking them.
What do I receive?
SVG, DXF, AI and CDR design files for the four-layer lighthouse. No assembly instruction guide is included. No physical artwork, material or mounting hardware is supplied.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
Contact 21CNCStudio to discuss permission before commercial use. Do not redistribute the digital files without the author’s permission.
03 /From the studio to your workbench
Make your coastal lighthouse.
View the Layered Lighthouse file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
