London Street Map / Laser-cut design
London. Four map layers.
SVG, DXF and CDR files for a four-layer London street map. Choose a round, square or hexagonal frame around the fine road pattern and winding river.
Digital design · SVG + DXF + CDR
No physical model or materials are shipped.
01 /The design
A river through the street network.
The river winds through the dense street detail, with London lettering along the map edge. The preview compares three frame shapes; a customer photograph shows the square version cut in natural wood.
The package supplies SVG, DXF and CDR design files for the four-layer artwork. Choose your outline before preparing the matching layers, and inspect the detail at your intended cutting size.
Four map layers
Keep the matching layers together throughout preparation.
Three frame shapes
Choose the round, square or hexagonal version.
A cut example
The customer photograph shows the square map beside a laser cutter.
A real build
Made from the files.
A physical build, with the maker’s choice of materials and finish.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Check the current layout dimensions and fine road connections before preparing your sheets. Scale every layer equally, cut a detailed test section and check the stack before fixing it together.
Before you start.
- Design
- Four-layer London street map
- Vector formats
- SVG, DXF, CDR
- Frame options
- Round, square or hexagonal
Which frame shapes are included?
The design includes round, square and hexagonal frames. Use the matching four layers for your chosen outline and keep their scale consistent.
What do I receive?
SVG, DXF and CDR design files for the four-layer London street map with three frame options. An assembly guide is not confirmed. No physical map or material is supplied.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
Contact 21CNCStudio to discuss permission before commercial use. Do not redistribute the digital files without the author’s permission.
03 /From the studio to your workbench
Choose your London map shape.
View the London Street Map file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
