Small Truck / Laser-cut design
A small truck. One cutting sheet.
SVG and DXF files for a small truck with an open-sided cabin and four wheels. Build it from a single-sheet cutting layout and follow the included PDF assembly guide.
Digital design · SVG + DXF · PDF guide
No physical model or materials are shipped.
01 /The design
A small body with an open cabin.
The cabin openings reveal the steering wheel and interior, while the roof frame joins the upright windscreen to the rear body. Original renders show the side, rear and view into the cabin.
With 3 mm material, the finished model measures 140 × 64 × 71 mm. The 3 mm cutting layout is 297 × 225 mm; the 1/8-inch version uses a 312 × 238 mm layout.
Compact finished model
The 3 mm build is 140 mm long.
Two material versions
Choose the 3 mm or 1/8-inch files to match your material.
PDF assembly guide
Use the guide to identify the parts and construction sequence.
Views & details
A closer look.
Original design renders from different angles. Select an image for a larger view.
02 /At your workbench
Choose your material.Make it fit.
Measure first.
Check your actual material thickness and the matching file version. Test the slots and kerf on a small cut.
Check the layout.
Open the supplied design in compatible laser software. Check that the layout fits your machine’s usable work area.
Follow the guide.
Use the PDF assembly guide to identify the parts and work through the construction sequence.
Plan this build.
The sheet sizes describe the complete layouts. Check them against your usable cutting area, measure the material and test the fitted connections before cutting the full truck.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design files
- SVG + DXF
- Assembly guide
- PDF included
- Material versions
- 3 mm / 1/8 inch
- Finished size at 3 mm
- 140 × 64 × 71 mm (L × W × H)
- 3 mm cutting layout
- 297 × 225 mm
- 1/8-inch cutting layout
- 312 × 238 mm
How much cutting area does the layout need?
The 3 mm version uses a 297 × 225 mm layout. The 1/8-inch version uses 312 × 238 mm. These are sheet layouts; the finished 3 mm truck is 140 × 64 × 71 mm.
What do I receive?
Digital SVG and DXF design files and a PDF assembly guide. No physical model, material or hardware is shipped.
Can I change the scale?
Scale every part equally. Slots and tabs change with the design, so the material thickness must change in the same proportion; the finished dimensions also change. Test the fit and kerf before cutting all the parts.
Can I use the design commercially?
The files are for personal use. Contact 21CNCStudio before commercial use or selling finished items. Do not resell, share or redistribute the digital files without permission.
03 /From the studio to your workbench
Build the small truck.
View the Small Truck file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
