Illinois Layered Map / Laser-cut design
Illinois. Eight layers.
SVG, DXF, AI, CDR and EPS files for eight-layer Illinois artwork. Tall buildings rise through the state outline, with smaller architectural shapes and a red guitar near the base.
Digital design · SVG + DXF + AI + CDR + EPS
No physical model or materials are shipped.
01 /The design
A tall skyline within the Illinois shape.
The long Illinois silhouette frames buildings of different heights, with the state name above them. A small guitar adds a contrasting shape near the lower edge of the composition.
The design uses eight layers at a listed size of 260 × 149 mm. Prepare the matching layers together in a supported vector format and choose finishes that keep the building details clear.
Eight layers
Arrange the matching shapes to build the skyline and foreground.
Illinois outline
The tall state silhouette and lettering frame the composition.
Five vector formats
SVG, DXF, AI, CDR and EPS files are supplied.
02 /At your workbench
Choose your material.Make it fit.
Check the detail.
Inspect the smallest bridges and fine cutouts at your chosen size. Cut a small sample before committing a full sheet.
Keep the layers aligned.
Use the same scale for every layer. Check the design against your laser’s usable work area before cutting.
Stack in order.
Arrange the cut layers in order and check their alignment before fixing them together.
Plan this build.
Inspect the small building openings, guitar detail and narrow state outline before cutting. Keep all eight layers at one scale, test a detailed section and check their order and alignment.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design
- Eight-layer Illinois artwork
- Vector formats
- SVG, DXF, AI, CDR, EPS
- Design size
- 260 × 149 mm
Is this a street map of Illinois?
This is a layered scene inside the state outline, with buildings and a guitar. It is not a street network or a topographic map.
What do I receive?
SVG, DXF, AI, CDR and EPS files for the eight-layer Illinois artwork. An assembly guide is not confirmed. No physical artwork or material is supplied.
Can I change the scale?
Scale every layer by the same percentage. The overall dimensions change, and fine bridges can become fragile when reduced. Material thickness changes the depth of the stack; check any alignment features or fitted connections and test a small section first.
Can I use the design commercially?
The files are for personal use. Contact 21CNCStudio before commercial use or selling finished items. Do not resell, share or redistribute the digital files without permission.
03 /From the studio to your workbench
Build your Illinois scene.
View the Illinois Layered Map file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
