Japanese Pagoda / Laser-cut design
Japanese Pagoda.
A Japanese pagoda inspired by Seiganto-ji Temple. Laser-cut a wooden architectural model for display or a 28 mm tabletop scene.
Digital design · SVG + DXF · PDF guide
No physical model or materials are shipped.
01 /The design
A slender spire above deep roofs.
Deep overhanging roofs and fine balcony rails build up to the pagoda's slender spire. The enclosed lower floor gives it a distinct shape beside the more open Samurai Pagoda.
The design allows interior lighting to be added. Plan any lighting installation as part of your own build: LEDs, wiring and other physical components are not included in the digital download.
449 mm
Approximate listed height, with a 220 × 220 mm footprint.
Interior lighting
A design that allows you to add lighting components of your own.
Two layouts
Approximately thirteen sheets: 260 × 260 mm at 3 mm, or 275 × 275 mm at 1/8 inch.
A real build
Made from the files.
A physical build, with the maker’s choice of materials and finish.
02 /At your workbench
Choose your material.Make it fit.
Measure first.
Check your actual material thickness and the matching file version. Test the slots and kerf on a small cut.
Check the layout.
Open the supplied design in compatible laser software. Check that the layout fits your machine’s usable work area.
Follow the guide.
Use the PDF assembly guide to identify the parts and work through the construction sequence.
Plan this build.
Check the material layout for the version you choose. If you plan to add lighting, work out the component placement and access before closing the model.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design files
- SVG + DXF
- Assembly guide
- PDF included
- Material versions
- 3 mm / 1/8 inch plywood
- Listed approximate size
- 220 × 220 × 449 mm (W × L × H)
- 3 mm material layout
- Approximately 13 sheets, 260 × 260 mm
- 1/8 inch material layout
- Approximately 13 sheets, 275 × 275 mm
- Miniatures
- 28 mm
Are the lights included?
No. This is a digital download. The model is designed to allow interior lighting, but any lighting components and their installation are part of your own build.
What do I receive?
Digital SVG and DXF design files and a PDF assembly guide. No physical model, material or hardware is shipped.
Can I change the scale?
Scale every part equally. Slots and tabs change with the design, so the material thickness must change in the same proportion; the finished dimensions also change. Test the fit and kerf before cutting all the parts.
Can I use the design commercially?
For personal use. Contact 21CNCStudio before commercial use or selling finished items. Do not resell, share or redistribute the digital files without permission.
03 /From the studio to your workbench
Build your Japanese pagoda.
View the Japanese Pagoda file package and its current terms on Etsy.
View files on EtsyDigital design files.No physical model, material or hardware is shipped.
