Dollywood Klondike Katie No. 192 / Laser-cut design
Klondike Katie.
A 1:32 model of Dollywood’s Klondike Katie No. 192, with its tender. The documented design uses SVG and DXF cutting files with a PDF assembly guide; the marketplace link is being updated.
Digital design · SVG + DXF · PDF guide
No physical model or materials are shipped.
01 /The design
Katie, with her tender.
This Klondike Katie project contains the locomotive and its matching tender at 1:32 scale. The cylindrical boiler, open cab area and spoked wheels lead into the tender behind it.
Rolling wheels and opening hatches in the cab and tender are part of the documented design. This is an advanced build with a PDF assembly guide. Contact the studio about the files while the exact marketplace link is being updated.
No. 192
Klondike Katie is a separate design from Dollywood No. 70.
1:32
The design's listed scale; resizing also changes material thickness and finished dimensions.
With tender
The listed assembled size covers the locomotive and tender together.
02 /At your workbench
Choose your material.Make it fit.
Measure first.
Check your actual material thickness and the matching file version. Test the slots and kerf on a small cut.
Check the layout.
Open the supplied design in compatible laser software. Check that the layout fits your machine’s usable work area.
Follow the guide.
Use the PDF assembly guide to identify the parts and work through the construction sequence.
Plan this build.
Match the locomotive and tender versions before cutting. The documented design uses 3 mm or 1/8 inch plywood; confirm the version included in the eventual marketplace listing.
At the 3 mm material scale, no individual part exceeds 290 mm. This refers to one part, not the assembled model or the whole cutting layout. Rescaling changes that limit.
Before you start.
- Design files
- SVG + DXF
- Assembly guide
- Material versions
- 3 mm / 1/8 inch plywood
- Scale
- 1:32
- Listed size with tender
- 817 × 103 × 170 mm (L × W × H)
- Design contents
- No. 192 locomotive and tender
- Build level
- Advanced
Where can I get the files?
The exact marketplace link for this design is being updated. You can contact 21CNCStudio about Klondike Katie No. 192; this page does not yet provide a purchase or download link.
What do I receive?
The documented design uses SVG and DXF with a PDF guide. The exact marketplace link and its current package are being checked; this page does not offer an active download.
Can I change the scale?
Scale every part equally. Slots and tabs change with the design, so the material thickness must change in the same proportion; the finished dimensions also change. Test the fit and kerf before cutting all the parts.
Can I use the design commercially?
The documented design is for personal use. Contact 21CNCStudio about commercial permission. Confirm the final file package and terms on the marketplace listing when its link is available.
03 /From the studio to your workbench
Klondike Katie files.
Marketplace link being updated.
The exact file listing for Dollywood Klondike Katie No. 192 is not linked yet. Contact the studio about this design.
Ask about this modelDigital design files.No physical model, material or hardware is shipped.
